Briquetting Machine

The briquetting machine is a kind of mechanical equipment for pressing powder particles into a spherical shape. The granular powder is often difficult to form and can be formed quickly and stably by a briquetting machine, such as coke powder molding, pulverized coal forming, desulfurization gypsum molding, dry powder molding, metal slag forming and iron filings. The use of a briquetting machine not only reduces dust, but also facilitates return and utilization, and can control capacity and reduce transportation difficulty.

Are you interested in our machines? Get Quotation
Briquetting Machine

Why FTM Briquetting Machine ?

The briquetting machine can be used to suppress coal powder, iron powder, coking coal, aluminum powder, iron filings, iron oxide scale, carbon powder, slag, gypsum, tailings, sludge, kaolin, activated carbon, coke, and other materials, and it is widely used in refractory materials, power plants, metallurgy, chemicals, energy, transportation, heating, and other industries. The formed material after the briquetting machine is energy-saving and environmentally friendly, easy to transport, improves the utilization rate of waste, and has good economic and social benefits.

The briquetting machine transmits power to two press rolls simultaneously through the reducer and rotates the two press rolls toward each other. During the rotation of the two rolls, the material naturally enters the ball mold on the press roll. As the pressure roller rotates, the pressure on the material changes from small to large. When the material is rotated to the line contact point of the two rollers, the pressure of the material has reached a peak. Under the action of the huge line pressure, the material becomes a finished ball from powder.

Technical Data

Model Roll diamter
(mm)
Roll width
(mm)
Total pressure
(t)
Main motor power
(kw)
Output
(t)
Weight
(t)
GY520-150 520 196 150 55 2.2-3.5 13
GY650-220 650 200 220 110 4-6.5 19.2
GY750-300 750 280 300 185 6-8.5 34
GY1000-350 1000 440 350 250 10-15 50.8
GY1000-450 1000 504 450 280 14-17 58.5
GY1000-500 1000 504 500 315 15-20 58.5
GYS1000-500 1000 600 500 280 17-21 56.5
GY1000-540 1000 900 540 185Kw×2 30-35 60
GY1200-800 1200 900 800 280Kw×2 40 110
GY1400-1000 1400 1000 1000 400Kw×2 50 156

Advantages

1. The produced products have strong durability and high production efficiency and are suitable for producing coal, coke, mineral powder, and refractory materials.

2. It has the advantages of high pressure, simple operation, convenient maintenance, and reliable operation.

3. The unique finished product and the double material conveying make the structure and application of the machine more practical.
